LAPP 0031380/500 vod za prijenos podataka UNITRONIC® FD Li2YCY (TP) A crna 500 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 29.11.2025 do 05.12.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

6,200.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Tip kabela	UNITRONIC® FD Li2YCY (TP) A
Vanjski Ø	6 mm
Boja	crna
Sadržaj	500 m
Bez halogena	ne
Proizvođač-br. dijela	0031380/500
Izolacijski material	polivinilhlorid
Raspon temperature, fiksna instalacija (min.)	-40 °C
Raspon temperature, fiksna instalacija (maks.)	70 °C
Tip	UNITRONIC® FD Li2YCY (TP) A BE 4X2X0,14
UV resistant	FALSE
Nominal cross section conductor	0.14 mm²
Material core insulation	Other
Core identification	Colour
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Permitted cable outer temperature after assembling without vibration	-40-70 °C
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	FALSE
Outer diameter approximate	6.7 mm
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
AWG size	Other
Min. permitted bending radius, stationary application/permanent installation	26.8 mm
Specification core insulation	Polyethylene (PE)
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	vod za prijenos podataka
