LAPP 0034121/100 vod za prijenos podataka JE-Y(ST)Y plava boja 100 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 29.11.2025 do 05.12.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

675.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Tip kabela	JE-Y(ST)Y
Vanjski Ø	8 mm
Boja	plava boja
Sadržaj	100 m
Bez halogena	ne
Proizvođač-br. dijela	0034121/100
Izolacijski material	polivinilhlorid
Raspon temperature, fiksna instalacija (min.)	-30 °C
Raspon temperature, fiksna instalacija (maks.)	70 °C
Tip	JE-Y(ST)Y...BD EB 4X2X0,8
UV resistant	FALSE
Nominal cross section conductor	0.8 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Flame retardant	According to IEC/EN 60332-1-2
Colour outer sheath	Blue
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Permitted cable outer temperature after assembling without vibration	-30-70 °C
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	FALSE
Outer diameter approximate	8.5 mm
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Min. permitted bending radius, stationary application/permanent installation	51.0 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	vod za prijenos podataka
