LAPP 1002180/1000 vod za prijenos podataka ÖLFLEX® CLASSIC 115 CH SF (TP) crna 1000 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 29.11.2025 do 05.12.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Tip kabela	ÖLFLEX® CLASSIC 115 CH SF (TP)
Vanjski Ø	9 mm
Boja	crna
Sadržaj	1000 m
Bez halogena	da/ne
Proizvođač-br. dijela	1002180/1000
Raspon temperature, fiksna instalacija (min.)	-40 °C
Raspon temperature, fiksna instalacija (maks.)	80 °C
Tip	ÖLFLEX® CLASSIC 115 CH SF (TP) 3x2x0,75
UV resistant	TRUE
Nominal cross section conductor	0.75 mm²
Material core insulation	Other
Core identification	Colour
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Other
Conductor category	Class 6 = very flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	TRUE
Outer diameter approximate	9.6 mm
Low smoke (according to EN 61034-2)	TRUE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Bare
Min. permitted bending radius, moving application/free movement	144.0 mm
Min. permitted bending radius, stationary application/permanent installation	57.6 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	vod za prijenos podataka
