LAPP 1032055/100 vod za prijenos podataka UNITRONIC® ROBUST crna 100 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 29.11.2025 do 05.12.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

935.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Tip kabela	UNITRONIC® ROBUST
Broj žica	7 x
Vanjski Ø	4 mm
Boja	crna
Sadržaj	100 m
Bez halogena	ne
Proizvođač-br. dijela	1032055/100
Raspon temperature, fiksna instalacija (min.)	-50 °C
Raspon temperature, fiksna instalacija (maks.)	90 °C
Tip	UNITRONIC® ROBUST C 7x0,14
UV resistant	TRUE
Nominal cross section conductor	0.14 mm²
Core identification	Colour
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Other
Permitted cable outer temperature after assembling without vibration	-50-90 °C
Number of cores	7
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	FALSE
Outer diameter approximate	4.9 mm
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
Min. permitted bending radius, moving application/free movement	73.5 mm
Min. permitted bending radius, stationary application/permanent installation	29.4 mm
Specification core insulation	Polypropylene (PP)
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	vod za prijenos podataka
