LAPP 2170889/500 mrežni kabel ETHERLINE® MARINE zelena 500 m

Kataloški br:: 3350868 - 62
Oznaka:: 2170889/500
EAN:: 4044774753256

(0)

Kataloški br:: 3350868 - 62
Oznaka:: 2170889/500
EAN:: 4044774753256

Dostupno online (Skladište: Njemačka)

Dostava: 19.06.2025 do 21.06.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

32,965.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Tip kabela	ETHERLINE® MARINE
Broj žica	4 x
Vanjski Ø	6 mm
Boja	zelena
Sadržaj	500 m
Bez halogena	da/ne
Proizvođač-br. dijela	2170889/500
Raspon temperature, fiksna instalacija (min.)	-25 °C
Raspon temperature, fiksna instalacija (maks.)	70 °C
Tip	ETHERLINE® MARINE FRNC FC CAT.5 2x2xAWG22
UV resistant	TRUE
Core identification	Colour
Colour outer sheath	Green
Material outer sheath	Other
Permitted cable outer temperature after assembling without vibration	-25-70 °C
Number of cores	4
Halogen free according to EN IEC 60754-2	FALSE
Low smoke according to EN IEC 61034-2	FALSE
Outer diameter approximate	6.5 mm
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	TRUE
AWG size	Other
Min. permitted bending radius, moving application/free movement	51.8 mm
Min. permitted bending radius, stationary application/permanent installation	20.7 mm
Specification core insulation	Polypropylene (PP)
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	mrežni kabel

Opis

ETHERLINE® MARINE FRNC FC CAT.5 2x2xAWG22 Ethernet kabel; fleksibilan; ETHERNET/IP, PROFINET; PROFINET® Primjena: Tip B; Cat.5e; SF/UTP; Bez halogena; zelena
