Kabeli za vučne lance

LAPP kontrolni vod 2 x 0.5 mm² 0026300/500 500 m

Kataloški br:: 3388442 - 62
Oznaka:: 0026300/500
EAN:: 4044774623733

(0)

Kataloški br:: 3388442 - 62
Oznaka:: 0026300/500
EAN:: 4044774623733

Dostupno online (Skladište: Njemačka)

Dostava: 25.08.2025 do 27.08.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

3,640.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Broj žica	2 x
Poprečni presjek (po žili)	0.5 mm²
Presjek	2 x 0.5 mm²
Vanjski Ø	5.3 mm
Sadržaj	500 m
Nazivni napon	500 V
Nazivni napon U0	300 V
Proizvođač-br. dijela	0026300/500
Tip	ÖLFLEX® CLASSIC FD 810 P 2X0,5
Nominal cross section conductor	0.5 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Numbers
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyurethane (PUR)
Conductor category	Class 6 = very flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	2
Outer diameter approximate	5.3 mm
With protective conductor	FALSE
Low smoke (according to EN 61034-2)	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Conductor surface	Bare
Min. permitted bending radius, moving application with forced guidance	39.8 mm
Min. permitted bending radius, moving application/free movement	39.8 mm
Min. permitted bending radius, stationary application/permanent installation	21.2 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® CLASSIC FD 810 P 2X0,5 upravljački kabel; 2X0,5; Core-Line; U 0 /U: 300/500 V; PUR; Identifikacija žice: brojevi; vučni lanac

Ovaj tekst je strojno preveden.
