LAPP kontrolni vod 2 x 1 mm² 10036021/100 100 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	100 m
Presjek	2 x 1 mm²
Poprečni presjek (po žili)	1 mm²
Proizvođač-br. dijela	10036021/100
Tip	ÖLFLEX® CLASSIC 115 CH 2X1
Nazivni napon	500 V
Vanjski Ø	6.6 mm
Nazivni napon U0	300 V
Broj žica	2 x
Nominal cross section conductor	1 mm²
Material core insulation	Other
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Other
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	2
Outer diameter approximate	6.6 mm
With protective conductor	FALSE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Bare
AWG size	Other
Min. permitted bending radius, moving application/free movement	132.0 mm
Min. permitted bending radius, stationary application/permanent installation	39.6 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Vrsta proizvoda	kontrolni vod
