Kabeli za vučne lance

LAPP kontrolni vod 3 x 0.5 mm² 0026301/500 500 m

Kataloški br:: 3388443 - 62
Oznaka:: 0026301/500
EAN:: 4044774623771

(0)

Kataloški br:: 3388443 - 62
Oznaka:: 0026301/500
EAN:: 4044774623771

Dostupno online (Skladište: Njemačka)

Dostava: 26.08.2025 do 28.08.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

3,980.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Broj žica	3 x
Poprečni presjek (po žili)	0.5 mm²
Presjek	3 x 0.5 mm²
Vanjski Ø	5.7 mm
Sadržaj	500 m
Nazivni napon	500 V
Nazivni napon U0	300 V
Proizvođač-br. dijela	0026301/500
Tip	ÖLFLEX® CLASSIC FD 810 P 3G0,5
Nominal cross section conductor	0.5 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Numbers
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyurethane (PUR)
Conductor category	Class 6 = very flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	3
Outer diameter approximate	5.7 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Conductor surface	Bare
Min. permitted bending radius, moving application with forced guidance	42.8 mm
Min. permitted bending radius, moving application/free movement	42.8 mm
Min. permitted bending radius, stationary application/permanent installation	22.8 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® CLASSIC FD 810 P 3G0.5 upravljački kabel; 3G0.5; Core-Line; U 0 /U: 300/500 V; PUR; Identifikacija žice: brojevi; vučni lanac

Ovaj tekst je strojno preveden.
