LAPP kontrolni vod 4 x 1 mm² 1026718/500 500 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 26.08.2025 do 28.08.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

2,690.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Broj žica	4 x
Poprečni presjek (po žili)	1 mm²
Presjek	4 x 1 mm²
Vanjski Ø	6.9 mm
Sadržaj	500 m
Nazivni napon	500 V
Nazivni napon U0	300 V
Proizvođač-br. dijela	1026718/500
Tip	ÖLFLEX® CHAIN 809 4G1,0
Nominal cross section conductor	1 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 5 = flexible
Nominal voltage U0	300 V
Number of cores	4
Outer diameter approximate	6.9 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
AWG size	Other
Min. permitted bending radius, moving application with forced guidance	69.0 mm
Min. permitted bending radius, moving application/free movement	69.0 mm
Min. permitted bending radius, stationary application/permanent installation	27.6 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod
