LAPP kontrolni vod 4 x 6 mm² 11356505/1000 1000 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	1000 m
Presjek	4 x 6 mm²
Poprečni presjek (po žili)	6 mm²
Proizvođač-br. dijela	11356505/1000
Tip	ÖLFLEX® CLASSIC 100 CY 300/500V 4G6
Nazivni napon	500 V
Vanjski Ø	15.8 mm
Nazivni napon U0	300 V
Broj žica	4 x
Nominal cross section conductor	6 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Nominal voltage U	500 V
Colour outer sheath	Other
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	4
Outer diameter approximate	15.8 mm
With protective conductor	TRUE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Min. permitted bending radius, moving application/free movement	316.0 mm
Min. permitted bending radius, stationary application/permanent installation	94.8 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Vrsta proizvoda	kontrolni vod
