Kabeli za vučne lance

LAPP kontrolni vod 5 x 0.75 mm² 1026762/500 500 m

Kataloški br:: 3388195 - 62
Oznaka:: 1026762/500
EAN:: 4044776031192

(0)

Kataloški br:: 3388195 - 62
Oznaka:: 1026762/500
EAN:: 4044776031192

Dostupno online (Skladište: Njemačka)

Dostava: 26.08.2025 do 28.08.2025

Prodaja i slanje od: Architektengruppe S71 d.o.o.

4,715.00 KM

sa PDV Troškovi dostave

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Broj žica	5 x
Poprečni presjek (po žili)	0.75 mm²
Presjek	5 x 0.75 mm²
Vanjski Ø	7.7 mm
Sadržaj	500 m
Nazivni napon	500 V
Nazivni napon U0	300 V
Proizvođač-br. dijela	1026762/500
Tip	ÖLFLEX® CHAIN 809 CY 5G0,75
Nominal cross section conductor	0.75 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 5 = flexible
Nominal voltage U0	300 V
Number of cores	5
Outer diameter approximate	7.7 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
AWG size	Other
Min. permitted bending radius, moving application with forced guidance	77.0 mm
Min. permitted bending radius, moving application/free movement	77.0 mm
Min. permitted bending radius, stationary application/permanent installation	30.8 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod

Opis

ÖLFLEX® CHAIN 809 CY 5G0.75 upravljački kabel; 5G0.75; Basic-Line; U 0 /U: 300/500 V; PVC; Identifikacija žice: brojevi; Oklopljeno; UL priznat; vučni lanac

Ovaj tekst je strojno preveden.
