LAPP 0021836/500 priključni vod 4 x 50 mm² 500 m

(0)

Rasprodano

Prodaja i slanje od: Architektengruppe S71 d.o.o.

135,580.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Vrsta proizvoda	priključni vod
Broj žica	4 x
Poprečni presjek (po žili)	50 mm²
Presjek	4 x 50 mm²
Vanjski Ø	36.2 mm
Sadržaj	500 m
Nazivni napon	750 V
Nazivni napon U0	450 V
Proizvođač-br. dijela	0021836/500
Tip	ÖLFLEX® ROBUST 200 4G50
Nominal cross section conductor	50 mm²
Material core insulation	Other
Core identification	Colour
Nominal voltage U	750 V
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Other
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-50-80 °C
Nominal voltage U0	450 V
Number of cores	4
Outer diameter approximate	36.2 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	FALSE
Conductor surface	Bare
Min. permitted bending radius, moving application/free movement	362.0 mm
Min. permitted bending radius, stationary application/permanent installation	144.8 mm
Specification core insulation	Polypropylene (PP)
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	TRUE

ÖLFLEX® ROBUST 200 4G50 priključni kabel; 4G50; U 0 /U: 450/750 V; TPE; Oznaka žice: boje; fleksibilno

Ovaj tekst je mašinski preveden.
