LAPP kontrolni vod 1121361/500 500 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

16,325.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	500 m
Proizvođač-br. dijela	1121361/500
Tip	ÖLFLEX® CLASSIC 110 CY BK 0,6/1kV 5G4
Nazivni napon	1000 V
Vanjski Ø	17.7 mm
Nazivni napon U0	600 V
Material core insulation	Polyvinyl chloride (PVC)
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	1 kV
Colour outer sheath	Black
Material outer sheath	Polyvinyl chloride (PVC)
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Number of main cores	5
Identification main cores	Numbers
Nominal voltage U0	0.6 kV
Outer diameter approximate	17.7 mm
With protective conductor	TRUE
Min. permitted bending radius, moving application/free movement	354.0 mm
Min. permitted bending radius, stationary application/permanent installation	106.2 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Vrsta proizvoda	kontrolni vod
