LAPP kontrolni vod 2 x 0.5 mm² 1136752/500 500 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	500 m
Presjek	2 x 0.5 mm²
Poprečni presjek (po žili)	0.5 mm²
Proizvođač-br. dijela	1136752/500
Tip	ÖLFLEX® CLASSIC 115 CY 2X0,5
Nazivni napon	500 V
Vanjski Ø	5.8 mm
Nazivni napon U0	300 V
Broj žica	2 x
Nominal cross section conductor	0.5 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Numbers
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	2
Outer diameter approximate	5.8 mm
With protective conductor	FALSE
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Min. permitted bending radius, moving application/free movement	116.0 mm
Min. permitted bending radius, stationary application/permanent installation	34.8 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod

Prosječna ocjena

0.00 od 5 zvjezdica

Još nema recenzija ovog proizvoda, ali to možete promijeniti.
