LAPP kontrolni vod 3 x 0.5 mm² 0027531/500 500 m
- Kataloški br:
- 3388498 - 62
- Oznaka:
- 0027531/500
- EAN:
- 4044774631219
- Kataloški br:
- 3388498 - 62
- Oznaka:
- 0027531/500
- EAN:
- 4044774631219
LAPP kontrolni vod 3 x 0.5 mm² 0027531/500 500 m
4,030.00 KM
Komada
Prodaja i slanje od:
Architektengruppe S71 d.o.o.
4,030.00 KM
sa PDV
Troškovi dostave
Komada
Tehničke specifikacije
Tehničke specifikacije
| Sadržaj | 500 m |
| Presjek | 3 x 0.5 mm² |
| Poprečni presjek (po žili) | 0.5 mm² |
| Proizvođač-br. dijela | 0027531/500 |
| Tip | ÖLFLEX® FD 855 P 3G0,5 |
| Nazivni napon | 500 V |
| Vanjski Ø | 5.5 mm |
| Nazivni napon U0 | 300 V |
| Broj žica | 3 x |
| Nominal cross section conductor | 0.5 mm² |
| Material core insulation | Other |
| Core identification | Numbers |
| Nominal voltage U | 500 V |
| Colour outer sheath | Grey |
| Conductor material | Copper |
| Material outer sheath | Polyurethane (PUR) |
| Conductor category | Class 6 = very flexible |
| Permitted cable outer temperature after assembling without vibration | -50-80 °C |
| Nominal voltage U0 | 300 V |
| Number of cores | 3 |
| Outer diameter approximate | 5.5 mm |
| With protective conductor | TRUE |
| Low smoke (according to EN 61034-2) | FALSE |
| Halogen free according to EN 60754-1/2 | FALSE |
| Oil resistant according to EN IEC 60811-404 | FALSE |
| Conductor surface | Bare |
| AWG size | Other |
| Min. permitted bending radius, moving application with forced guidance | 27.5 mm |
| Min. permitted bending radius, moving application/free movement | 27.5 mm |
| Min. permitted bending radius, stationary application/permanent installation | 16.5 mm |
| Specification core insulation | Other |
| Specification material outer sheath | Other |
| Cable geometry | Round |
| Core identification according to HD 308 S2 | FALSE |
| Vrsta proizvoda | kontrolni vod |
Opis
Opis
ÖLFLEX® FD 855 P 3G0.5 upravljački kabel; 3G0.5; Extended-Line; U 0 /U: 300/500 V; PUR; Identifikacija žice: brojevi; UL priznat; vučni lanac
