LAPP kontrolni vod 4 x 0.75 mm² 0021900/500 500 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

3,290.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	500 m
Presjek	4 x 0.75 mm²
Poprečni presjek (po žili)	0.75 mm²
Proizvođač-br. dijela	0021900/500
Tip	ÖLFLEX® ROBUST 210 4G0,75
Nazivni napon	500 V
Vanjski Ø	6.3 mm
Nazivni napon U0	300 V
Broj žica	4 x
Nominal cross section conductor	0.75 mm²
Material core insulation	Other
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Black
Conductor material	Copper
Material outer sheath	Other
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-50-80 °C
Nominal voltage U0	300 V
Number of cores	4
Outer diameter approximate	6.3 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	FALSE
Conductor surface	Bare
Min. permitted bending radius, moving application/free movement	94.5 mm
Min. permitted bending radius, stationary application/permanent installation	25.2 mm
Specification core insulation	Polypropylene (PP)
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod
