LAPP kontrolni vod 4 x 1 mm² 10019963/500 500 m
- Kataloški br:
- 3388247 - 62
- Oznaka:
- 10019963/500
- EAN:
- 4044774591025
- Kataloški br:
- 3388247 - 62
- Oznaka:
- 10019963/500
- EAN:
- 4044774591025
LAPP kontrolni vod 4 x 1 mm² 10019963/500 500 m
3,745.00 KM
Komada
Prodaja i slanje od:
Architektengruppe S71 d.o.o.
3,745.00 KM
sa PDV
Troškovi dostave
Komada
Tehničke specifikacije
Tehničke specifikacije
| Sadržaj | 500 m |
| Presjek | 4 x 1 mm² |
| Poprečni presjek (po žili) | 1 mm² |
| Proizvođač-br. dijela | 10019963/500 |
| Tip | ÖLFLEX® CLASSIC 110 H 4G1 |
| Nazivni napon | 500 V |
| Vanjski Ø | 6.6 mm |
| Nazivni napon U0 | 300 V |
| Broj žica | 4 x |
| Nominal cross section conductor | 1 mm² |
| Material core insulation | Other |
| Core identification | Numbers |
| Nominal voltage U | 500 V |
| Colour outer sheath | Grey |
| Conductor material | Copper |
| Material outer sheath | Other |
| Conductor category | Class 5 = flexible |
| Nominal voltage U0 | 300 V |
| Number of cores | 4 |
| Outer diameter approximate | 6.6 mm |
| With protective conductor | TRUE |
| Low smoke (according to EN 61034-2) | TRUE |
| Halogen free according to EN 60754-1/2 | TRUE |
| Conductor surface | Bare |
| Reaction-to-fire according to EN 13501-6: Class | Cca |
| Reaction-to-fire according to EN 13501-6: Smoke production | s1 |
| Reaction-to-fire according to EN 13501-6: Acidity | a1 |
| AWG size | Other |
| Min. permitted bending radius, moving application/free movement | 66.0 mm |
| Min. permitted bending radius, stationary application/permanent installation | 26.4 mm |
| Specification core insulation | Other |
| Specification material outer sheath | Other |
| Cable geometry | Round |
| Core identification according to HD 308 S2 | FALSE |
| Vrsta proizvoda | kontrolni vod |
Opis
Opis
ÖLFLEX® CLASSIC 110 H 4G1 upravljački kabel; 4G1; U 0 /U: 300/500 V; HFFR; Identifikacija žice: brojevi; UL priznat; fleksibilan
Ovaj tekst je strojno preveden.
Ovaj tekst je strojno preveden.
Ocjene kupaca
Ocjene kupaca
Prosječna ocjena
0.00 od 5 zvjezdica
Još nema recenzija ovog proizvoda, ali to možete promijeniti.
Pribor za ovaj prooizvod
- Esencijalni (11)
