LAPP kontrolni vod 4 x 50 mm² 00350273/500 500 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	500 m
Presjek	4 x 50 mm²
Poprečni presjek (po žili)	50 mm²
Proizvođač-br. dijela	00350273/500
Tip	ÖLFLEX® CLASSIC 100 CY 450/750V 4G50
Nazivni napon	750 V
Vanjski Ø	38.8 mm
Nazivni napon U0	450 V
Broj žica	4 x
Nominal cross section conductor	50 mm²
Material core insulation	Polyvinyl chloride (PVC)
Core identification	Colour
Flame retardant	According to IEC/EN 60332-1-2
Nominal voltage U	750 V
Colour outer sheath	Other
Conductor material	Copper
Material outer sheath	Polyvinyl chloride (PVC)
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	450 V
Number of cores	4
Outer diameter approximate	38.8 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Eca
Min. permitted bending radius, moving application/free movement	776.0 mm
Min. permitted bending radius, stationary application/permanent installation	232.8 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	TRUE
Vrsta proizvoda	kontrolni vod
