LAPP kontrolni vod 5 x 0.75 mm² 1127413/1000 1000 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

0.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	1000 m
Presjek	5 x 0.75 mm²
Poprečni presjek (po žili)	0.75 mm²
Proizvođač-br. dijela	1127413/1000
Tip	ÖLFLEX® 127 HSLH 5G0,75
Nazivni napon	500 V
Vanjski Ø	6.9 mm
Nazivni napon U0	300 V
Broj žica	5 x
Nominal cross section conductor	0.75 mm²
Material core insulation	Other
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Other
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	5
Outer diameter approximate	6.9 mm
With protective conductor	TRUE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Cca
Reaction-to-fire according to EN 13501-6: Smoke production	s1a
Reaction-to-fire according to EN 13501-6: Acidity	a1
Min. permitted bending radius, moving application/free movement	103.5 mm
Min. permitted bending radius, stationary application/permanent installation	27.6 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Vrsta proizvoda	kontrolni vod
