LAPP kontrolni vod 7 x 1.5 mm² 1123314/500 500 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

8,155.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	500 m
Presjek	7 x 1.5 mm²
Poprečni presjek (po žili)	1.5 mm²
Proizvođač-br. dijela	1123314/500
Tip	ÖLFLEX® CLASSIC 135 CH 7G1,5
Nazivni napon	500 V
Vanjski Ø	10 mm
Nazivni napon U0	300 V
Broj žica	7 x
Nominal cross section conductor	1.5 mm²
Material core insulation	Other
Core identification	Numbers
Nominal voltage U	500 V
Colour outer sheath	Grey
Conductor material	Copper
Material outer sheath	Other
Conductor category	Class 5 = flexible
Permitted cable outer temperature after assembling without vibration	-40-80 °C
Nominal voltage U0	300 V
Number of cores	7
Outer diameter approximate	10 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	TRUE
Halogen free according to EN 60754-1/2	TRUE
Conductor surface	Bare
Reaction-to-fire according to EN 13501-6: Class	Dca
Reaction-to-fire according to EN 13501-6: Smoke production	s1b
Reaction-to-fire according to EN 13501-6: Acidity	a1
AWG size	16
Min. permitted bending radius, moving application/free movement	200.0 mm
Min. permitted bending radius, stationary application/permanent installation	60.0 mm
Specification core insulation	Other
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	kontrolni vod
