LAPP vod za servo 4 x 2.5 mm² 0027927/1000 1000 m

(0)

Dostupno online (Skladište: Njemačka)

Dostava: 24.03.2026 do 30.03.2026

Prodaja i slanje od: Architektengruppe S71 d.o.o.

36,680.00 KM

Komada

(0)

Prikaži recenzije

Tehničke specifikacije

Sadržaj	1000 m
Presjek	4 x 2.5 mm²
Poprečni presjek (po žili)	2.5 mm²
Proizvođač-br. dijela	0027927/1000
Tip	ÖLFLEX® SERVO FD 796 CP 4G2,5+(2x0,5)
Nazivni napon	1000 V
Vanjski Ø	12.6 mm
Nazivni napon U0	600 V
Broj žica	4 x
Nominal cross section conductor	2.5 mm²
Material core insulation	Other
Nominal voltage U	1 kV
Colour outer sheath	Orange
Conductor material	Copper
Material outer sheath	Polyurethane (PUR)
Conductor category	Class 6 = very flexible
Permitted cable outer temperature after assembling without vibration	-50-90 °C
Nominal voltage U0	0.6 kV
Number of cores	4
Outer diameter approximate	12.6 mm
With protective conductor	TRUE
Low smoke (according to EN 61034-2)	FALSE
Halogen free according to EN 60754-1/2	FALSE
Oil resistant according to EN IEC 60811-404	FALSE
Conductor surface	Bare
AWG size	14
Min. permitted bending radius, moving application with forced guidance	94.5 mm
Min. permitted bending radius, moving application/free movement	94.5 mm
Min. permitted bending radius, stationary application/permanent installation	50.4 mm
Specification core insulation	Polypropylene (PP)
Specification material outer sheath	Other
Cable geometry	Round
Core identification according to HD 308 S2	FALSE
Vrsta proizvoda	vod za servo

Prosječna ocjena

0.00 od 5 zvjezdica

Još nema recenzija ovog proizvoda, ali to možete promijeniti.
